Sunflower seed preparation and solvent extraction plant with capacity ranging
from 100 t/d to 5,000 t/d.
We provide tailored designs of sunflower seed dehulling process are delivered
to meet your requirement for protein content in extraction meal. One-stage
dehulling and two-stage dehulling are available to suit your specific needs.
The purpose of
preparation is to extract a portion of oil by mechanical pressing while
providing pressing cakes for extraction plant. Main processes include: Seed
Cleaning & Weighing, Cracking & Dehulling, Flaking, Cooking, Pressing,
Oil Residue Separation.
The meal is highly
appreciated thanks to its high protein content as animal feed, especially for
large breeding. The most delicate point in case of insufficient decorticating
is the excessive content of cellulose of the meal, which makes it indigestible
for some animals (poultry and pork).
The sunflower oil contains approximately 1.5% of lecithin (phosphatides) as main
part of the unsaponifiables. Separated before neutralization, it is
re-incorporated into the extracted meal.
In the unsaponifiables of the sunflower oil, the waxes also represent a fair
amount. Those waxes, at cold temperature, are quite insoluble in the
triglycerides and have a tendency to precipitate, which gives the oil a
turbidity aspect, which is detrimental to marketing even if waxes are not
contrary to the intrinsic value of the oil. As the waxes come from the shells,
it points out the importance of the decorticating, and the latter is
counterbalanced by the fact that a certain amount of shells are necessary for a
good prepressing and by the oil loss through the entrained seed.
The waxes can be eliminated from the oil by winterizing. Different processes
have been developed in that respect, dewaxing by centrifuge after
neutralization, dry winterizing with or without filter aid.
1. Cleaning &
Weighing Section
Sunflower seeds from daily bin or warehouse is treated by magnetic separator,
weighing scale and screener to remove impurities.
2. Cracking & Dehulling Section
The purpose of softening is to adjust moisture, temperature and tenacity of
sunflower seeds before flaking.
3. Flaking Section
The purpose of flaking is to flake the broken flower seeds into thin flakes
(from 0.3 to 0.35mm) for the subsequent oil extraction through mechanical
pressing. In addition, flakes thickness can be adjusted through roll pressure
adjustment device.
4. Cooking Section
Horizontal Drum Rotary Cooker is designed to adjust
temperature and moisture of sunflower seeds flakes prior to mechanical
pressing, improving oil yield greatly.
5. Pressing Section
Sunflower seeds is a kind of high oil-containing oilseed. Generally it is
necessary to extract a portion of oil by mechanical pressing prior to
subsequent process. Pressing cakes containing residual oil from 14% to 18% is
then treated by solvent extraction while crude oil is to be filtered.
6. Oil Residue Separation Section
Due to high content of residue in crude oil, it is necessary to separate oil
residue by oil drag conveyor firstly, crude oil then enters to settling tank
for further separation. Collected residue is returned to pressing section while
crude oil from settling tank is pumped to horizontal screw centrifuge or leaf
filter for further removing impurities.
7. Cooling Section
Hydraulic turning cooler with complete set of wind network system is designed
to cool down pre-pressing cakes to 55~60℃, then cakes is conveyed to the extraction plant.
-By MYANDE
